Different Tooling Options Available for your stators with different cost investment to match your needs;
Motor Stator Stamping Production
Motor stator stamping

Motor Stator Stamping Tool Material: High Performance Tunsten Steel;

Thickness:   0.1mm,0.15mm, 0.2mm, 0.35mm,0.5mm,etc

Mold Type : Progressive die stamping mould for stator rotor , single mould for stator rotor ,

Stator Lamination Technology: Inter-lock, Loose Lamination, Welding, Stator bonding etc...

Life Span: More than 50-150 Million Punching Times

Silicon Steel in Common Storage：

ThicknessMaterial Model
0.1mmST-100/10JNEX900(Supercore)
0.15mmST-150/15CS1200
0.2mm

20JNEH1200/20JNEH1500/B20AV1200

NO20-1200/20SW1200

0.35mm35JNE250/33JNE230/35WW250/35CS210/B35A270
0.5mmB50A290/B50A350/B50A470/B50A270/50WW600，50A600

Other Material assigned by Customer is acceptable.

Outer Stator Stamping

OD:  Customized

ID:  Customized

Silicon Steel Thickness: 0.1mm, 0.15mm, 0.2mm, 0.35mm, 0.5mm

Stator Height: 1mm-200mm Customized

Tolerance: 0.02 per drawing


Outer Stator Sample
Motor Stator lamination
Motor  lamination
Motor Stator lamination
Motor Stator lamination
motor stator stamping
motor stator stamping
Motor Stator lamination
Inner Stator Stamping

OD: Customized

ID:  Customized

Silicon Steel Thickness: 0.1mm, 0.15mm, 0.2mm, 0.35mm, 0.5mm

Statator Height: 1mm-200mm Customized

Tolerance: 0.02 Per Drawing

Outer Stator Sample(1)
motor lamination
motor lamination
Motor Lamination
Motor stator stamping
Slotless Stator Stamping

OD: Customized

ID:  Customized

Silicon Steel Thickness: 0.1mm, 0.15mm, 0.2mm

Statator Height: 1mm-50mm Customized

Tolerance: 0.02 per drawing

Outer Stator Sample(1)(1)
slotless stator lamination
slotless stator lamination
slotless motor stator
slotless motor stator
Slotless Stator
Slotless Stator
Helix/skewed Stator Stamping

A helix/skewed stator stamping and lamination mould includes two parts: one mold for punching and another mould with Servo Motor to control the rotation angle of silicon steel sheet.

OD: Customized

ID:   Customized

Silicon Steel Thickness: 0.1mm, 0.15mm, 0.2mm, 0.35mm, 0.5mm

Statator Height: 1mm-200mm Customized

Tolerance: 0.04

Angle Tolerance: +/-1 Degree

Helix Stator Sample
skewed stator core
skewed stator core
Skewed stator stack
Skewed stator stack
rotated stator stack
rotated stator stack
skewed motor stator
skewed motor stator
